VMA U2 (MM) Vertical 2000 RPM

Table size: 1525 × 305 mm
X-axis travel: 1075 mm
Y-axis travel: 310 mm
Z-axis travel: 450 mm
Feed rate X/Y: 15–900 mm/min
Feed rate Z: 7.5–530 mm/min
Rapid traverse X/Y: 3000 mm/min
Rapid traverse Z: 1200 mm/min
Vertical spindle taper: ISO40
Horizontal spindle taper: ISO50
Vertical spindle speed: 90–2000 RPM
Horizontal spindle speed: 40–1800 RPM
Spindle motor: 11 kW
Feed motor: 2.2 kW
Pump motor: 0.11 kW
Milling vice
Face mill arbor
Face mill Ø80 mm
4 collet chucks
25 collets
3 drill chucks
2 Morse taper sleeves ISO40/MT2
2 Morse taper sleeves ISO40/MT3
2 Morse taper sleeves ISO40/MT4
1 Morse taper sleeve ISO50/MT2
7 face mill arbors ISO40
1 face mill arbor ISO50
1 long arbor ISO50 Ø40 mm
Weight: 2900 kg
