Weinig Profimat 26 Super

Four-side planer
Plastic equipment

1st spindle, lower horizontal spindle
11 kW
Diameter 40 mm
Speed: 6,000 rpm
Shaft without rebate device without planer spindle can be retrofitted

2nd spindle, right vertical spindle
Common motor with left vertical spindle 11 kW
Diameter 40 mm
Speed: 6,800 rpm

3rd spindle, left vertical spindle
Common motor with right vertical spindle 11 kW
Diameter 40 mm
Speed: 6,800 rpm

4th spindle, upper horizontal spindle
11 kW
Diameter 40 mm
Speed: 6,800 rpm

5th spindle, lower horizontal spindle
11 kW
Diameter 40 mm
Speed: 6,800 rpm

6th spindle, 360° universal spindle
11 kW
Diameter 40mm
Speed: 6,800 rpm

Feed system:
5-24 m/min
Motor: 4 kW

Planing table: 2.5 m

Operation:
Both axes of all spindles (except the first spindle) are equipped with mechanical digital displays.

ATS system
Automatic 2-axis control for spindles 3 and 4
