Weinig UNIMAT 3

4-Side Moulder with 7 Shafts
Condition: Used

Technical Specifications:
- Capacities: th.xw. : 120 x 230 mm
- Minimum and maximum width: 20-230 mm
- Minimum and maximum height: 8-120 mm
- Minimum length of workpiece alone: ​​750 mm
- Variable speed: 5 to 24 m/min
- Spindle speed: 6,000 rpm

Composition:
- Infeed table: 2500 mm
- Motorized adjustment of machining width and height
- All adjustments are located on the front panel, accessible with the cover closed
- Each adjustment is equipped with a SIKO digital counter
- Enveloping and soundproofing enclosure with a large panoramic window
- 6 tool holder spindles Ø40 mm
1. Lower horizontal shaft: 5.5 kW (7.5 hp)
2. and 3. Right and left spindle: 11 kW (15 hp) 4. Vertical spindle: 5.5 kW (7.5 hp)
5. Upper horizontal spindle: 7.5 kW (10 hp)
6. Lower horizontal spindle: 7.5 kW (10 hp) 7. Universal spindle: 5.5 kW (7.5 hp)
