Weisser-Heilbronn Engine Lathe 2000 rpm JUNIOR

Technical data
Turning length: 1500 mm
Turning diameter: 475 mm
Turning diameter over face-slide: 290 mm
Turning diameter in gap: 655 mm
Turning speed range: 14 - 2000 rpm
Feeds longitudinal: 0.05 - 0.736 mm/min
Spindle passage: 61 mm
Tailstock: MK 4
Quill stroke: 200 mm
Quill diameter: 70 mm
Spindle head: DIN 55022 GR 6
Voltage: 380 V
Total power requirement: 7.5 kW
Weight: 2400 kg
Dimensions: 3080 x 1160 x 1485 mm

Features
Robust electric motor-driven conventional lathe
KLOPFER 4-jaw chuck Ø 200
MULTIFIX steel holder with 3 inserts
Movable steel holder guard
Adjustable bed stop
Movable tailstock with center point
Swiveling machine light
Machine swing feet
Chip guard movable from behind
Emergency stop button at the front
Original operating instructions
Machine card
