Weisser SIEMENS SINUMERIK 840D Control 5000 RPM Univertor AS 400 2 Axis

Turning Diameter 250 mm
Turning Length 400 mm
Control Siemens 840 D
Swing Diameter Max. 300 mm
Workpiece Length Max. 400 mm

Travel X-Axis 280 mm
Feed X-Axis 0.1 – 30 m/min
Rapid Traverse X-Axis 30 m/min
Travel Z-Axis 1150 mm
Feed Z-Axis 0.1 – 60,000 mm/min

Rapid Traverse Z-Axis 60 m/min
Spindle Bearing Diameter 90 mm
Spindle Head DIN 55026 Size A6
Turning Speeds 1 – 5000 RPM
Tool Taper Capto C4
Total Power Requirement 45 kW
Weight 11 t
Machine Dimensions 7.0 × 5.0 × 3.2 m

SIEMENS SINUMERIK 840D Control
Screw Conveyor with Chip Breaker and Return Pumping Station
NC-Steady SMW-SLU-1-OLD Ø10-70 mm
12-Fold Tool Turret SAUTER 0.5.460.220
NC Tailstock
Artis Monitoring
Pickup-Loading Incl. Conveyor
Without Coolant System (Connected to Central Supply)
Inspection Under Power Possible
