Windmoller & Holscher Miraflex 8 1000 mm

Number of colors 8
Overhaul/renovation We camera and inspection system
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1050
Print width (mm) 1000
Min print repeat (mm) 300
Max print repeat (mm) 800
Unwinder type Turret automatic
Max reel diameter unwinder (mm) 800
Rewinder type Turret automatic
Max reel diameter rewinder (mm) 800
Drying 2 zones, 4 fans, 2 gas burners
Videocamera year 2024 with automatic quality inspection system
Corona treatment YEs
Vyscosity control automatic
Washing system TURBOCLEAN automatic washing system
Inking system closed chamber doctor blades
Anilox 26 aniloxes
Print Sleeves : 295 sleeves - 8x300mm, 8x310mm, 8x315mm, 8x320mm, 8x325mm, 12x330mm, 12x340mm,
8x350mm, 8x355mm, 8x360mm, 8x370mm, 8x380mm, 8x385mm, 8x390mm, 8x400mm, 8x410mm, 8x420mm,
8x430mm,8x440mm, 8x450mm, 8x460mm, 8x470mm, 18x480mm, 8x500mm, 8x510mm, 12x520mm, 8x530mm,
8x540mm, 8x560mm, 8x570mm, 9x580mm, 8x590mm, 8x620mm, 8x660mm
Max. working speed 400m/min
Automatic Impression setting „EASY SET HD“ Automatic Register setting „EASY REG S“ Colour maching system „EASY COL“
