Winter MULTIMAX 170 350/170 Crawler multi-saw
Ref :
2729668-15-AW
Condition :
Used
Manufacturer :
Winter
Model :
MULTIMAX 170 350/170
Short Description :
Crawler multi-saw
Year(s) :
-
Quantity :
1
Location :
Seller or machines location:
EUROPE (Central and Eastern)
EUROPE (Central and Eastern)
Track width 350 mm
working width of the shaft with saws 355 mm
max blade diameter 450 mm
max cutting height 170 mm
diameter of the disk hole 70 mm
dimensions of the top 1850x790mm
*in advance:
pawl +
2 smooth, metal sliding shafts +
shaft with saws +
3 smooth, metal sliding shafts +
*from down:
lead bar +
pawl +
caterpillar +
Pulling toothed shaft, metal
central lubrication, electric +
Smooth feed speed regulation +
electric lifting of the body up / down about 1kW
feed motor 2,2kW
main engine 75kW
overall dimensions length / width / height 2600x1800x1700mm
weight 2700kg
