Winter UNIMAX 5-23

Four-sided planer
Max width of the workpiece 230 mm
max. height of the workpiece 160 mm
number of spindles 5
1) horizontal lower 230mm 7,5kW
2) vertical right 160mm 5,5kW
3) vertical left 160mm 5,5kW
4) horizontal top 230mm, electrically adjustable up / down 7,5kW
5) horizontal lower 230mm 7,5kW
all spindles adjustable up / down, right left +
diameter of spindles 40 mm
spindle revolutions 6000 revolutions / min

- from above:
6 introductory pulling, toothed rollers, including 2 double +
2 single rubber pulling output rollers +

- from down:
input shaft, toothed pulling, metal, torsion +
metal, smooth output shaft +
on the side insertion pressure +
pneumatically adjustable shafts +
length of the countertop 2020 mm
central lubrication +
electrical setting of planing thickness from the desktop +
Smooth feed speed regulation 6-30m / min
feed on cardan shaft +
feed motor 4,5kW
diameters of the extraction pipe 5x150mm
dimensions length / width / height 3850x1850x1960mm
weight around 3800kg
