Zayer MEMPHIS 10000-U 250 mm 6,000 RPM

X-Axis Travel: 10,011 mm
Y-Axis Travel: 1,960 mm
Z-Axis Travel: 1,112 mm
Working Feed Rate (X/Y/Z): 20,000 mm/min
Rapid Traverse (X/Y/Z): 30,000 mm/min
Control: HEIDENHAIN TNC-430M
9-Axis CNC
Table Size: 9,500 × 2,000 mm
Maximum Table Load: 20,000 kg
Distance Between Columns: 2,850 mm
Distance from Table to Vertical Spindle Nose: 1,291 mm
Distance from Table to Horizontal Spindle Nose: 1,365 mm
Automatic 45° Milling Head
Indexing Positions: 360,000 × 0.001°
Spindle Taper: DIN 69871 AD50
Maximum Spindle Speed: 6,000 RPM
Spindle Power: 37 kW
Automatic Tool Changer
Tool Magazine Capacity: 100 Tools
Tool Holder: ISO 7388-2 B50
Maximum Tool Diameter: 250 mm
Maximum Tool Diameter with Adjacent Tools: 125 mm
Maximum Tool Length: 400 mm
Maximum Tool Weight: 25 kg
Double Position Tool Change
Through-Spindle Coolant
External Coolant
Coolant Unit with Paper Filter and Magnetic Separator
Coolant Tank Capacity: 1,000 L
Coolant Pump Flow Rate: 30 L/min
Adjustable Coolant Pressure: Up to 20 bar
Secondary Coolant Pump Flow Rate: 60 L/min
Secondary Coolant Pressure: 2.5 bar
2 Cross Chip Conveyors
2 Operator Panels
2 Portable Handwheels
HEIDENHAIN HR-410 Handwheels
2 Cleaning Guns
T-Slots: 8 × 28 mm × 250 mm
Total Power Requirement: 103.40 kVA
