Used Spinning machines (Open End)
244 results400 spindle 533 rotor dia original cleaner Year(s) : 2013 Location : ASIA (China - Taiwan - HKG)
Price : On request
More details312 spindles rotor dia 34 2 manipulator corolab cleaner running condition Year(s) : 2004 Location : ASIA (China - Taiwan - HKG)
Price : On request
More details* No of rotors : 312 * Yarn Clearer Make : Uster Quantum 2 * Rotor Type : T ( Magnetic Type ) * 31mm Faceplate Year(s) : 2003 Location : AMERICA North (USA-Canada-Mexico)
Price : On request
More detailsWith Corlab Location : ASIA (China - Taiwan - HKG)
Price : On request
More detailsFOUR MACHINES ARE IN PERFECT WORKING CONDITION PACKAGED AND READY TO SHIP Location : Russia
International Socks Ltd
Jun, 30
NUMBER OF ROTORS 264 EACH MACHINE Year(s) : 1997 Location : MIDDLE EAST
Price : On request
More details1. Cotton Blow room – 1 set ( capacity 500-800 kgs/h cotton), composed of: - Blendomat – 36 m rails for 3 Year(s) : 2007 Location : EUROPE (Central and Eastern)
Price : On request
More details* Rotors: 288 * Corolab * Corolab XQ * B 174 DR * Rotor Diâmeter : 31 mm * Rotor type : T 331 * Cylindrical Year(s) : 1997 Location : AMERICA (Central and South)
Price : On request
More details264 rotors Machine is producing 24 hours a day with up-to-date maintenance efficiency above 90%, producing 10 Year(s) : 1994 Location : AMERICA (Central and South)
Price : On request
More detailsIncluding: - 3 Open end with 280 rotors, year 2006 (2 machines) and 2011 (1 machine), 2 robots - 3 Open end wi Year(s) : 2006 Location : EUROPE (Western and Northern)
Price : On request
More detailswith all upgrade software 216 Rotors MULTILOT 5 108 Rotor whit waxer and 108 whitout waxer Rotor T640 or T634 Year(s) : 2006 Location : EUROPE (Western and Northern)
Price : On request
More details1 x Saurer Schlafhorst BD7-432, 2020, 432 Rotor, 43mm Rotor 1 x Saurer Schlafhorst BD-448, 2014, 448 Rotor, 54 Year(s) : 2014, 2020 Location : MIDDLE EAST
Price : On request
More detailsSaurer open end Model: BD448 416 rotors 34 rotors Year(s) : 2016 Location : ASIA (China - Taiwan - HKG)
Price : On request
More detailsR20, Rieter 2001, 300-280 rotors per machines R40, Rieter, 280 rotors per machines Year(s) : 2001, 2002 Location : AMERICA North (USA-Canada-Mexico)
Price : On request
More detailsMANUFACTURING YEAR // 2015 __ 2015 __ 2016 ROTOR DIA // 31 (2015)__ 36 (2015) __ 40 (2016) ROTOR TYPE // K 63l Year(s) : 2015, 2016 Location : ASIA (South)
Price : On request
More detailsTruetzschler Blowroom 2001 BDT 019 / 2300 BDT 019 / 1730 MPM10/1600 MSI1600 CXL4/1600 DX FOL 1600 LVSA/B PWSE, Year(s) : 2001, 2002, 2003 Location : AMERICA North (USA-Canada-Mexico)
Price : On request
More detailsNumber of Rotors Per Machine: 552 Rotor Dia: 31, 36 and 40 Take up Speed: 250m/min Waxing: Yes Max. Rotor Spee Year(s) : 2015, 2016 Location : ASIA (South)
Price : On request
More details416 spindles running at mill floor Year(s) : 2011 Location : MIDDLE EAST
Price : On request
More details416 spindles 54mm rotor diameter Running. Year(s) : 2008 Location : MIDDLE EAST
Price : On request
More details4 x Rieter C60 carding, 1 pc 2011, 2 pcs 2007, 1 pc 2006 1 x Rieter RSB-D 40 Draw Frame, 2006 1 x Rieter RSB- Year(s) : 2003, 2016 Location : MIDDLE EAST
Price : On request
More detailsRotor Spinning Make in Czech Republic 320 Rotors of machine 54 mm rotors dia. with Separate Side running Very Year(s) : 2002 Location : ASIA (South East)
Price : On request
More detailsRIETER R 40 320 rotors year 2004 2 robots 33-XT5-B-AE rotors Air cradle B 174 DN 64 openers Uster Quantum Year(s) : 2004 Location : MIDDLE EAST
Price : On request
More details2 X RIETER OPEN END MODEL: R40 2010 YEAR 500 ROTORS 3 piecers Rieter yarn clearer 33mm rotors B174DN combing r Year(s) : 2010 Location : ASIA (China - Taiwan - HKG)
Price : On request
More details48 positions D130 mm rotors Needle opening rollers Ceramic nozzle Year(s) : 1985 Location : EUROPE (Western and Northern)
Price : On request
More details20 positions With piecing robot Excellent condition, used for sample work only Year(s) : 1998 Location : AMERICA North (USA-Canada-Mexico)
Price : On request
More detailsNos. 24 rotors (1 spinning section only) SRK 6” Waxing device Opening rollers B 174 DN – B 20 DN Rotor type T Year(s) : 2003 Location : EUROPE (Western and Northern)
Price : On request
More detailsYou can find used Open End Spinning machines on Wotol
The main manufacturers of Spinning machines (Open End) are Schlafhorst, Rieter, Elitex, Saurer, Trützschler, Savio, Hdb, Ingolstadt, Muratec, Titan, Zinser.
You will find ACO Autocoro SE9, SE10, SE11, SE12, R60, R40, R20, BT903, BT905, BT923, BD200
Open-end spinning is cleaper spinning method where the yarn is twisted by rotating at the hap or break in the flow (the fibers wrap around the yarn vs spinning one long piece of yarn). Open end spinning offerd higher poductivity and less processed than ring spinning method but it gives products with a lower quality with frayed texture and poorer wear resistance. It is also called break spinning or rotor spinning.
Open end technology has been developped in the 30's. Elitex from CZ has developped the first rotor spinning machine running at 30000 rpm with its very well known BD200 model in 1965. The speed has increased rapidely at 100,000 rpm in the mid 70s. Noadays Open End is widely spred as a mass production spinning method.
Questions and answer corner from users
Q: Schlaforst ACO seems to be a very known machine for open-end. I have seen a complete mill with various models. Can you explain the difference?
A: There are 18 SE-9 168 unit frames - non Amsler equipped- 10 with 46 mm rotor and 8 with 40 mm rotor .
There are 10 SE-9 240 unit frames - 9, equipped with Amsler units- 46 mm rotor.
There are 8 SE-10 240 unit frames - non Amsler- 40 mm rotor.
We have enough of the 46 and 40 mm rotors to change them as styles dictated. All the 40 mm rotors are TT grove that we used in filling.
All the 46 mm rotors are U groove that we used in the Warp yarn frames.
There is an extra set of 46 mm TT rotors that we used in the 25P/75C mix- 240 rotors.
All frames have B174 combing rolls ( 100% ) but we have OS21 rings for combination poly/cotton yarns.
The 168 unit frames are 80' in length.
The 240 unit frames are 107' in length ( except Amsler frames, they are 109' because of Amsler control box mounted on top)
The SE10 240 unit frames are 108' in length.
All frames have 2 piecers ( robots ).
No frames have waxing devices.
SE-9 Rotor drive has a 23 kw on 1 end and 35 kw on the other end.
SE-10 Rotor Drive has a 35 kw on both ends.
Combing roll drive motor is 17 kw on both frame types.
All frames have Uster UPG Polyguard clearers.
Q: I want to buy some Schlafhorst SE9, SE10 Open end with 288 spindles how many containers do I need and how do you load the machines?
A: For one Schlafhorst SE9, SE10 Open end with 288 spindles you will need 2 complete 40FT high cube containers. The fees of the sections will be removed and the open end sections will be secured on special palettes made for this purpose. On section of open end will be on top of the other will be held by a metal frame to avoid any damage. We usually have these farmes made for few hundred dollars each.
Q: I have some questions about your used Schlafhorst Autocoro 8 Open end spinning machines from 2012 with 480 spindle:
What is the running count and rotor speed?
A : We are producing from 7s to 32s on these ACO8.
machine is running 12000 ~ 14000 ,It is up to count; but this machine can run much faster ; wewant to produce high quality ; that is why we run lower speed.
Q: Also please confirm the availability of Synchropiecing.
A : Yes ACO8 No 2 is 12 spindles ,the rest is 6 spindles
Q: What is the the feed can diameter
A : Can diameter 1100 X 500mm
Q: What is the machine length for 480 Rotor machine ?
A : Complete lenght on the mill floor is : 60790mm
Q: What yarn count can produce a usd Rieter BT 902 open end spinning machine with Exit 6'' 4º 20' ?
A : This Rieter BT-902 can do 8Nm – 20Nm.
