Automatic Feed 50,000# x 48" x 0.125" Feed Line
Ref :
2752460-3-AW
Condition :
Used
Manufacturer :
-
Model :
Automatic Feed
Short Description :
50,000# x 48" x 0.125" Feed Line
Year(s) :
2000
Quantity :
1
Location :
Seller or machines location:
AMERICA North (USA-Canada-Mexico)
AMERICA North (USA-Canada-Mexico)
Coil Weight Capacity 50,000#
Maximum Width Capacity 48"
Minimum Width Capacity 10"
Coil Outer Diameter 72"
Maximum Thickness at 48" 0.125"
Maximum Thickness at 24" 0.177"
Minimum Thickness at 48" 0.020"
Feeding Length 2" - 36"
Press Speed 60 SPM
Feedrate 100 Feet per Minute
Feeding Angle Adjustable
Feed Direction Right to Left
Controls Unico Drive System
Controls A/B PLC
Controls IBM
Controls Wonderware Operator Interface
Material CRS
Material HD Galvanized
Material Electro Galvanized
Line Components Reel Uncoiler
Line Components Coil Car
