Bystronic XPERT 40/1030 400 kN

- open height: 515 mm
- stroke: 200 mm
- throat: 0 mm
- tonnage: 400 kN
- the operating hours are also visible in the photo: showing 382 hours
- bending length: 1030 mm
- width between side frames: 1060 mm
- working height: 885 mm
- lower beam width: 120 mm
- Y-approach speed: 250 mm/s
- Y-working speed: 25 mm/s
- Y-return speed: 250 mm/s
- main motor power: 7,5 kW
- oil capacity, approx.: 100 litre

Backgauge
- type: P14HA3-HA6

X-axis
- X-axis travel: 300 mm
- max. backgauge range X-axis: 500 mm
- X-axis accuracy: 0,02 mm
- X-axis speed: 1500 mm/s

R-axis
- R-axis travel: 100 mm
- R-axis accuracy: 0,1 mm
- R-axis speed: 500 mm/s

Z1-, Z2-axis
- Z-axis travel, approx.: 955 mm
- Z-axis accuracy: 0,1 mm
- Z-axis speed: 2000 mm/s

X1-axis
- X1-axis travel: 0 mm
- X1-axis accuracy: 0 mm
- X1-axis speed: 0 mm/s

General dimensions
- length: 1520 mm
- width: 1584 mm
- height: 2449 mm
- side frame under-floor: 0 mm
- lower beam under-floor: 0 mm
- weight, approx.: 4 t
