Clausing Colchester ENGINE LATHES 2500 RPM 15" Professional Series

Clausing-Colchester 15" Professional Series
Year: 2011


SWING OVER BED ......................... 15.7"
SWING IN RMOVEABLE GAP ................. 23"
SWING OVER CROSS SLIDE ................. 9.7"
DISTANCE BETWEEN CENTERS ............... 50"
HOLE THRU SPINDLE ...................... 2.125"
SPINDLE NOSE ........................... D1-6" CAMLOCK
SPINDLE SPEEDS INFINITELY VARIABLE:
THREE GEARED RANGES ................ 14 - 2500 RPM
HEADSTOCK SPINDLE CENTER TAPER ......... #4 MORSE
TAILSTOCK SPINDLE CENTER TAPER ......... #5 MORSE
TAILSTOCK SPINDLE DIAMETER ............. 2.8"
TAILSTOCK SPINDLE TRAVEL ............... 5.5"
BED WIDTH ............................. 12.5"
LONGITUDINAL FEED RANGE ................ .0007" - .048" IPR
CROSS FEED RANGE = HALF OF LONGITUDINAL
ENGLISH THREADING RANGE (56) ........... 2 - 56 TPI
METRIC THREADING RANGE (51) ............ .2 - 14 mm
APPROX DIMENSIONS ...................... 99"L x 49"W x 51"H
APPROX WEIGHT .......................... 3,500 LBS

EQUIPPED WITH:
ELECTRONIC VARIABLE SPINDLE SPEED IN THREE GEARED RANGES
THROUGH AC INVERTER VARIABLE SPEED DRIVE
INDUCTION HARDENED & PRECISION GROUND BEDWAYS
UNIVERSAL GEARBOX ALLOWING FOR A COMPREHENSIVE RANGE OF
INCH/METRIC THREADS
ACU-RITE TWO AXIS DIGITAL READOUT9-3/4" SKINNER 3-JAW CHUCK
TAPER TURNING ATTACHMENT
4-JAW CHUCK
HARDINGE-SJORGEN COLLET CHICK
FACEPLATE
QUICK CHANGE TOOLPOST
MICROMETER CARRIAGE STOP
THREADING DIAL
TAILSTOCK
COOLANT SYSTEM
REMOVABLE CHIP PAN
10 HORSE POWER SPINDLE DRIVE MOTOR
