Correa A30/40 3000 r.p.m.

Retrofitted: 2025
Longitudinal traverse X: 4000 mm
Cross traverse Y: 1200 mm
Vertical traverse Z: 1000 mm
C axis (auto-indexing UDG head): every 2.5º
Control: HEIDENHAIN TNC-320
Electronic handwheel: HR-510
Coolant: external and internal high pressure through spindle
Spindle speed range: 20 - 3000 r.p.m.
Spindle power: 29.8 kW
Tool clamping system: hydraulic
Taper nose: ISO 50 (DIN 69871)
Pull stud: DIN 69872
Feedrate: 2 - 5000 mm/min
Rapid feedrate X/Y: 15000 mm/min
Rapid feedrate Z: 10000 mm/min
Table dimensions: 4500 x 1100 mm
Number of T slots: 8
T slot dimensions: 22 mm
Maximum weight on table: 8000 kg
Machine weight: 23500 kg
Machine dimensions: 11100 x 5392 x 3400 mm
Guarding: 2 sliding doors and perimeter wire-mesh fence
