DMG MORI MSX 805 III CNC color control 3000 RPM MORI NL 3000Y/3000 4 Axis

Turning diameter 16.5"
Turning length 122.9"
Distance between centers 126"
X1-axis travel 11.8"
Z1-axis travel 124.8"
Y1-axis travel 4.7"
C-axis indexing 0.00
Rapid traverse X1 1181 ipm
Rapid traverse Z1 1181 ipm
Rapid traverse Y1 597 ipm
Control MORI MSX 805 III CNC color control
Bar capacity 4"
Spindle speeds 3000 RPM
Spindle horsepower 40 hp
Spindle nose A2-8
Spindle bore diameter 4"
Milling spindle speed 6000 RPM
Milling spindle horsepower 7.5 hp
Chuck size 12"
Turret tool positions 12
Tailstock taper 4
Tailstock quill travel 3.9"
Tailstock travel 114"
Weight 30800
Chip conveyor
Tool presetter
Through-hole air chuck 12"
Programmable steady rest
(2) rotary tool holders
