Duplo 5000

DSF-2000 Sheet Feeder with Bookletmaker DBM500 and Trimmer DBM500T
DSF-2000 Digital Sheet Feeder

Feeding System - Belt suction feed system
Maximum paper loading volume - Tray A(Upper): 200 mm in height
Tray B(Lower): 60 mm
Paper Size
Width: 148 to 320 mm
Length: 200 to 500 mm
Paper Type - Tray A: Fine quality (52.3to 127.9gsm)
Art/Coated (79 to 127.9gsm)
Tray B (for cover): Fine quality (52.3 to 250gsm)
Art/Coated (79 to 157gsm)
Paper Type- Sheet
Maximum Process Speed - 200 sheets / min (A4)
Feed error detection- Double-feed, mis-feed, paper jamming(Paper feed section)
Other detection function Paper jamming(convenyance route), no-paper, upper door open/close, lower door open/close, bridge cover open/close, end mark error
Minimum Paper Size - 100 mm x 150 mm (postcard)

DBM-5000 BOOKLETMAKER :
( CORNER/SIDE/TOP STITCHING APPLICATION)
Sheet Size (Min./Max.) 4.72” x 5.52” to 13.82” x 14.33”
Paper Capacity Up to 30 sheets***
