Froriep Engine Lathe Variable Speed DS 2000-13/IV
Ref :
2740694-3-CP
Condition :
Used
Manufacturer :
Froriep
Type :
Engine Lathe
Spindle Speed :
Variable Speed
Model :
DS 2000-13/IV
Year(s) :
-
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
Distance between centres 13000 mm
Swing over bed 4000 mm
Swing over cross slide 2220 mm
Spindle bore 95 mm
Spindle power 70 kW
Max workpiece length on main chassis 13000 mm
Max workpiece length on elevated chassis 6500 mm
Max turning diameter with main cross slide 4000 mm
Max turning radius with secondary cross slide 2700 mm
Max stroke of cross slide 2220 mm
Max weight between centres 100 ton
Machine weight 140 ton
Two cross slides
Elevated chassis with movable cross slide
Designed for turbine shafts, large pulleys, rotors, and pistons
