Haas Haas 2-Axis CNC Control with 15" Color Monitor 1400 rpm ST-40 Big Bore Live Tooling 2 Axis

Haas ST-40 Big Bore Live Tooling
2013

Capacity: Swing 34.5 "
Swing Over Cross Slide 25.5 "
Distance Between Centers 44 "

Spindle: Spindle Speed: Minimum (RPM) 0 rpm
Maximum 1400 rpm
Spindle Bore 7 "
Main Motor 55 hp
Spindle Nose A2-11

Turret: Number Of Positions 12
Chuck: Diameter 18 "
Hole Thru 6.5 "
Number of Jaws 3

Equipped With:
Haas 2-Axis CNC Control with 15" Color Monitor
Memory lock Keyswitch, USB Port, Color Remote Jog Handle, Rigid Tapping
Belt-Type Chip Conveyor
18" 3-Jaw Hydraulic Chuck
Big Bore Spindle Option (7" Bore)
Extra Performance Option (55 hp, 12 hp Z-Axis Servo Motor)
High-Torque Live Tooling with C-Axis
Hybrid BOT/VDI 12 Position Turret
High Pressure Coolant System, 300 PSI
Automatic Tool Presetter
High Intensity Lighting
Early Power Failure Detection Module
Intuitive Programming System
Auxiliary Coolant Filter System
Programmable Servo Tailstock
