Homag EDGETEQ S-300

Edgebander, Model 1430 HF (Used)
• Feed Speed: Variable from 8 to 14 m/min.
• Workpiece Thickness: 8 to 60 mm.
• Edgebanding Thickness:
• Rolled Edgebanding (PVC, ABS, melamine): 0.3 to 3 mm
• Solid/Edged Edgebanding: Up to 8 mm.

• Minimum Workpiece Width:
• 70 mm (for thicknesses 8-22 mm).
• 120 mm (for thicknesses 23-40 mm).
• Machine Length: Approximately 4,773 mm.
Equipment and Attachments (Version 1430 HF)

• Finishing Attachments:
• Profile Scraper (for radius edges).
• Glue Scraper (flat).
• Polishing Brushes.

Equipment and Units (V) :
• Calibration Unit (Joint Trimming): For perfect panel alignment before gluing (diamond tools Ø 100 mm)
• Gluing System: Flexible Quickmelt unit allowing the use of EVA or PUR glue with quick changeover.
• End Cutting Unit: Dual-motor, pneumatically pivoting for straight or chamfered cuts.
• Flush Milling Unit: Manual or automatic adjustment depending on the options.
• Shape Milling Unit (FF20): For rounding corners and copying (essential for complete edge finishing).
• Multi-Level Technology: Allows quick switching between profiles (e.g., 1 mm radius to 2 mm radius) via the control.
• Pressure Zone: Heavy pressure zone to guarantee optimal glue bonding, even on 8 mm edges.
• Energy Saving: Incorporates EcoPlus technologies to reduce energy consumption
EXCLUDES START-UP AND TRAINING, CONNECTION TO VARIOUS ENERGY SOURCES
