JONSEN SG 1030 JS+D

Max Thickness: 80 mm
Table Width: 1000 mm
Number of Stations: 2
Wide Abrasive Belt Head (JS)
Contact Roller Diameter: 185 mm
Photo-electrical Controlled Abrasive Belt Tracking
Oscillating Air Cylinder for Automatic Abrasive Belt Tracking
Safety Limit Switches on Both Ends of Belt
Wide Abrasive Belt Size: W1030mm x L1900mm
Main Driving Motor: 11 KW
Linear Speed: 12 m/s fixed
Pneumatic Disk Brake on Main Motor (5 sec emergency stop)
Oscillating Disk Brush Station (D)
Motor: 7.5 KW
Conveyor: Standard Rubberized Belt Type
Conveyor Feed Speed: 2-9 m/min
Motorized Four-Pillar Synchronized Elevator Mechanism with Hand Wheel
Patented External Jack Screws
Magnetic Railing Sensor for Workpiece Thickness Calibration
Voltage: 480V, 60Hz, 3 Phase
Schneider or Equivalent Low-Voltage Equipment
Electrical Components with UL/ULc/CSA Marking
Centralized Push Button Control on Stainless Panel
Amp Meter to Monitor Main Motor Loading
Service Mode to Override Safety Switches
Comprehensive Safety Devices and Emergency Switches
Main Electrical Switch on Electrical Cabinet Door
Safety Interlocks on All Accessible Doors
M15 Digital Readout of Table Height
Compressed Air Working Pressure: 6 Bar
Air Pressure Regulator on Frame
Dimensions: L2200 x W2100 x H2100 mm
Weight: 2800 kg
Dry Operation
Dual Workstations: Wide Abrasive Belt Head and Oscillating Disk Brush
General Surface Sanding, Deburring, and Edge Rounding
