Lagun Gap Bed Engine Lathe 2000 RPM 14" x 40"

Swing Over Bed: 14"
Swing Over Cross Slide: 8.5"
Swing Over Gap: 20"
Distance Between Centers: 40"

Cross Slide Travel: 9"
Compound Slide Travel: 5"

Spindle Speeds: 16 Steps, 40–2000 RPM
Longitudinal Feeds: 0.002–0.066
Cross Feeds: 0.001–0.033

Threads (Inch): 2–72 TPI (45)
Threads (Metric): 2–14 mm (39)
Module Threads: 0.3–3.5 (18)
Diametral Threads: 8–44 (21)

Control: Manual
Spindle Nose: D1-6 Camlock
Spindle Bore: 2"
Chuck: 3-Jaw Chuck
Collet Closer: Included
Toolpost: KDK-150
Tailstock: Included
Tailstock Quill Diameter: 2"
Tailstock Quill Travel: 5.5"
Tailstock Taper: MT4

Bed Width: 10.25"
Motor Power: 5 HP / 2.5 HP
Motor Speed: 1700 RPM / 860 RPM
Voltage: 220V
Phase: 3

Machine Dimensions: 80" x 30" x 53"
Machine Weight: 2,800 lb
