Liebherr LC752 table 590mm max 750
Ref :
2744399-3-AW
Condition :
Used
Manufacturer :
Liebherr
Model :
LC752
Spindle Speed :
-
Short Description :
table 590mm max 750
Year(s) :
2022
Quantity :
1
Location :
Seller or machines location:
ASIA (North East)
ASIA (North East)
for sale in my stock in korea. (retrofit almost every part table worm and hob spindle)
making gears from here is about din 6.
Specifications Liebherr LC 752 CNC
System:fanuc 18imb (retrofit)
Max workpiece Ø 750 mm
Module max. 10/16 mm
Table diameter 590 mm
Table bore 120 mm
Axial path 600 mm
Cutter diameter 170 mm
Max. Cutter length 250 mm
Radial path 50 ... 590 mm
Total power requirement 42kW
Weight 12,000 kg
Dimensions 5.4 x 4.7 x 3.25 m
