Liebherr WSC 1200 Variable Speed Gear Shaping Machine
Ref :
2740129-3-GO
Condition :
Used
Manufacturer :
Liebherr
Model :
WSC 1200
Spindle Speed :
Variable Speed
Short Description :
Gear Shaping Machine
Year(s) :
2009
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
gear hobbing diameter external 1200 mm
gear hobbing diameter internal 1200 mm
gear hobbing width max. 260 mm
max. workpiece diameter 1500 mm
table diameter 900 mm
table bore diameter 320 mm
max. table load 95 kN
power capacity 30 kW
coolant pump 120 l/min
axial distance spindle–table 0–820 mm
shaping spindle diameter 125 mm
tool taper SK 45 DIN
weight 26 t
dimensions 8,073 × 6,183 × 4,375 m
stroke length min./max. 0 / 270 mm
stroke length adjustability 270 mm
stroke rate (double strokes) 10–270 DH/min
control Liebherr PC-NC
Chip conveyor
Cutting wheel holder SK 45 DIN
Cooler
Technical documentation
