LVD PPEB-EFL Turbo 220 ton x 4100 mm CNC
Ref :
2803440-3-CP
Condition :
Used
Manufacturer :
LVD
Model :
PPEB-EFL Turbo
Pressure :
220 ton x 4100 mm CNC
Year(s) :
-
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
Press Force: 220 ton
Bending Length: 4100 mm
Backgauge: CNC
Control: 2D Touch
Passage Between Uprights: 3150 mm
Max Stroke: 250 mm
Max Distance Between Table and Ram: 485 mm
Throat Depth: 500 mm
Table Width: 120 mm
Approach Speed: 120 mm/sec
Working Speed: 21 mm/sec
Return Speed: 200 mm/sec
Motor Power: 42 kW
Axes: Y1
Axes: Y2
Axes: X
Axes: X'
Axes: R
Axes: Z1
Axes: Z2
Axes: V
Easy-Form Laser Measuring System
CNC Crowning
Laser Safe Protection
Wila Hydraulic Upper Clamping
Wila Hydraulic Lower Clamping
Turbo Version
Machine Length: 5590 mm
Machine Depth: 2350 mm
Machine Height: 3317 mm
Weight: 20 ton
