Maier CNC Control: FANUC 31i-B 6,000 RPM MLK 26 F1.5 CNC Longitudinal Lathe 11 Axis

Axes: 11
Turning Diameter Over Bed: 32 mm
Spindle Bore: 32 mm
Spindle Stroke Channel 1/Z1: 180 mm (short turning), 340 mm (long turning)
Main Spindle Speed: 6,000 RPM
Main Spindle Motor Power: 5.5 / 3.7 kW
Counter Spindle (Channel 2/Z2) Turning Length: 340 mm
Counter Spindle Speed Range: 8,000 RPM
Collets: 1536E
Drive Motor Power: 5.5 / 3.5 kW
Total Power Requirement: 28.7 kW, 60 A
Machine Weight: 4.4 t
Footprint: 8.0 x 2.7 x 2.1 m
CNC Control: FANUC 31i-B
Counter Spindle: 1 unit
NC C-Axis: On main and counter spindles
Tool Holders: 5 fixed turning tool holders, 16 x 16 mm
Bar Loading Magazine: FMB Turbo Ø 3-36, 2018
Guide Channel: DM12
Chip Conveyor
Electronic Handwheel
High-Pressure System: KNOLL, 50 bar with paper band filter
Fire Protection System: KRAFT & BAUER
Extraction System
CE Certification
Documentation
