Mazak Control Smooth X 4,000 rpm INTEGREX i-300 x 1000 5 Axis

X-axis travel 615 mm
Y-axis travel 250 mm
Z-axis travel 1,077 mm
Tailstock travel 1,026 mm
B-axis travel -30° to +210°
5-axis simultaneous machining
Control Smooth X
Mazatrol turn-milling
EIA/ISO 5-axis simultaneous machining
5-axis machining package for Smooth X
Tool tip control 5-axis simultaneous
Spline fine interpolation
5-axis spline interpolation
G00 slope constant
Re-thread function
Synchronized thread cutting
Mazak Monitoring B
Renishaw RMP 60 probe
Max rotary diameter 658 mm
Max turning length 1,011 mm
Max bar capacity 80 mm
Main spindle speed 4,000 rpm
Main spindle power 30 kW
Main spindle torque 724 Nm
Spindle nose A2-8
Spindle bore 91 mm
Milling spindle speed 12,000 rpm
Milling spindle power 22 kW
Capto C6 interface
Tool magazine capacity 110 tools
Max tool diameter 90 / 125 mm
Max tool length 400 mm
3-jaw chuck Schunk ROTA THW Plus Ø315 mm
Programmable NC tailstock MK5
15 bar high-pressure pump
Hinged belt chip conveyor
Switch-on hours approx. 10,000 h
Machining hours approx. 1,500 h
