Mazak Mazatrol Smart 2-Axis CNC Control 3300 rpm QTS-350-II 2 Axis

Mazak QTS-350-II
2011

Capacity: Swing 28.35 "
Maximum Machining Diameter 16.5 "
Distance Between Centers 29 "

Spindle: Spindle Speed: Minimum (RPM) 0 rpm
Maximum 3300 rpm
Spindle Bore 4.41 "
Main Motor 30/40 hp
Spindle Nose A2-11

Turret: Number Of Positions 12
X-Axis Travel 10.13 "
Z-Axis Travel 28 "

Tailstock: Quill Diameter - "
Taper 5 MT
Body Travel 24 "

Chuck: Diameter 12 "
Hole Thru 4 "
Number of Jaws 3

Equipped With:
Mazatrol Smart 2-Axis CNC Control
Programmable Tailstock
Automatic Tool Eye
Chip Conveyor
USB Port
RS-232 Port
Coolant System with Tank and Pump
Multi Tap Transformer
All Available Manuals and Tool Holders
