Mori Seiki Mitsubishi M730UM 3000 rpm NLX3000/1250Y 3 Axis

X-axis travel: 280 mm
Y-axis travel: ±60 mm
Z-axis travel: 1370 mm
Control: Mitsubishi M730UM
Bar capacity: 90 mm
Maximum turning diameter: 420 mm
Turning length: 1260 mm
Swing over bed: 978 mm
Swing over cross slide: 808 mm
Main spindle speed: 3000 rpm
Main spindle motor: 22/18.5 kW
Spindle bore: 91 mm
Chuck: 15 in KITAGAWA
Spindle nose: A2-8
Driven tools: 10000 rpm
Turret: 12 positions
Tailstock travel: 1284 mm
Tailstock taper: MT5
High-pressure coolant: 10 bar
Chip conveyor
Air blow through spindle center
Tool measuring arm
Mist collector
Steady rest
Work area light
Dual chuck foot switch
Oil skimmer
Custom Macro common variables (200)
Machine dimensions: 5300 × 2500 × 2400 mm
Weight: 8900 kg
