Muller BZE 1600-40.7.1 1600 ton

Press Force: 1600 ton
Distance Between Columns: 3160 mm
Ram Stroke: 1450 mm
Maximum Daylight: 2250 mm
Table Size: 4000 x 2200 mm
Ram Pressure: 1000 ton
Blank Holder Pressure: 600 ton
Blank Holder Stroke: 1000 mm
Blank Holder Stroke with Adjustment: 1450 mm
Blank Holder Adjustment: 0 - 100 mm
Blank Holder Size: 4000 x 2200 mm
Die Cushion Pressure in Table: 360 ton
Die Cushion Stroke in Table: 275 / 400 mm
Ram Surface: 4000 x 2200 mm
Side Column Travel: 1100 mm
Die Cushion in Table: Hydraulic, Controlled
Die Cushion in Pusher: Hydraulic, Controlled
Oil Volume: 9000 l
Total Power: 390 kW
Weight: 250 ton
Machine Dimensions: 6.0 x 4.3 x 10.5 m
Head Press of Press Line
