Other 2850/1300M/MIN crescent tissue machine 2850mm 14-28g/㎡ 47
Ref :
2767912-2-CP
Condition :
New
Manufacturer :
Other
Type :
2850/1300M/MIN crescent tissue machine
Width :
2850mm
Gramages Range ( Gsm ) :
14-28g/㎡
Capacity :
47
Year(s) :
-
Quantity :
1
Location :
Seller or machines location:
ASIA (China - Taiwan - HKG)
ASIA (China - Taiwan - HKG)
Paper variety: Facial tissue paper,
toilet tissue paper Capacity:45tpd
Ration: 14-28g/㎡
Yankee dryer dia:Φ3660mm
web width on reeler: 2850mm
Yankee working staem pressure:0.8Mpa
Working speed: 1200m/min (dryer can)
Diameter of jumbo roll paper: Φ2500mm
Designed speed: 1300m/min
Steam consumption:1.8-2T / T
Dynamic balancing speed: 1300m/min
Water consumption:3-5T / T(Can recycled)
Main gauge:3600mm
Electric consumption:≤ 330kWh/t
Transmission: Ac frequency sectional drive
Dimension: 18000×8000×6500 (L*W*H)
Main drive power: 408.5kw(only paper machine) Type: Crescent forming paper machinery
