Romaco Noack N920, C150, PewoPack250, CT2000, Blistering Machine line

Romaco's Noack N 921 series of blister packaging machines
continues to set the standard for efficiency,
versatility, and technology in blister packaging.
Measuring less than four meters in length,
the wrap-around sealing machine still achieves
an output of up to 500 blisters per minute –
an unbeatable ratio of productivity to footprint.
It also features the latest servo technology,
industry-leading tool-free changeover times,
and now also features Noack's new single-panel concept
for easy integration, as well as QuickFeed,
the interchangeable air-sliding feed unit.

Highlights
• QuickFeed
• Latest servo technology for fast, tool-free format changes
• Full cGMP compliance
• Balcony design
• XML control with touchscreen operator panel
• Tool compatibility for continuous profitability
• Operator ergonomics
• Easy integration of online printing and security systems
• Advanced product handling
• Applications: tablets, capsules, softgel capsules, capsules
• Child-resistant/elder-friendly packaging
• Cold-formed aluminum
• Multi-layer topsheet materials
Key technical specifications
Max. film width: 210 mm
Max. forming depth: 12 mm
Max. forming cycles: 100/min.
Max. blister production 500/min
Max. film forming roll diameter 700 mm
Max. coating film roll diameter 280 mm

Uhlmann C150
Year of manufacture: 2004
Intermittent motion cartoner for packaging small and medium-sized blister batches – with high process reliability and a long service life.

Technical specifications at a glance:
Max. output 150 cartons/min.
Operating mode: Intermittent
Application: Blister
Max. carton size [A x W x H] 100 x 85 x 150 mm
Pitch 5"
Max. number of blisters 10
Max. blister stack height 80 mm
Closure types: Tuck-in and hot-melt

PEWO PACK 250:
Year of manufacture: 2000
Automatic packaging machine

Technical specifications at a glance:
Min./max. Bundle dimensions:
- 60 x 30 x 60 mm [L x W x H] 360 x 180 x 250 mm [L x W x H].
Cycle rate: up to 80 packs/min.
Power supply: 3x400V + N + PE / 50Hz.
Operating pressure: 5 bar.
Suitable films: PE material.
Film width: min.: 50 mm - max.: 250 mm.
Film thickness: min.: 25 μm - max.: 100 μm.
Roll diameter: max.: 300 mm.
T-4000 sealing machine with automatic flap folding.
Top and bottom sealing.
The power control with the SOCO SYSTEM regulator ensures efficient separation and high capacity.
The compact machine is available in two basic versions: the T-4000 and the T-4200. The machine can be easily
adjusted to the current crate size, and adjustments can be made from both sides.
Easy belt changes. Compact design.
Simple and economical maintenance.
Extensive range of accessories, e.g., wheels with brakes, packing tables, and conveyor belts.

Christ CT2000:
Year of manufacture: 2009

Collector Table
CT2000 – More flexibility and less time pressure for operators at the end of the line
The CT2000 collector table is a fully automatic collector table for the temporary storage of products.
• Compact, high-quality balcony construction
• Ergonomic design with ample foot and knee room for the operator
• Easy-to-clean stainless steel paneling
• Fast, tool-free format changeover with high repeatability
• Low maintenance
• Automatic detection of a fully loaded table and stopping of upstream machines

Technical details:
Operating voltage: 1x230 V 50 Hz
Control voltage: DC 24 V
