Sodick VL300Q

Work tank inner dimensions (W x D): 810 x 650 mm
U x V axis stroke 80 x 80 mm
Machine installation area (W x D) 2600 x 2950 mm
Machine tool dimensions (W x D x H) 1895 x 2180 x 1960 mm
Distance from floor to table top 900 mm
Max. workpiece size (W x D x H) 780 x 570 x 215 mm (flush)
X axis stroke 350 mm
Y axis stroke 250 mm
Max. taper angle ±15° (thickness: 120mm)
Z axis stroke 220 mm
Max. weight of workpiece 500 kg (flush)
Machine tool weight 2400 kg
Wire diameter φ0.10-φ0.3 mm
Wire tension 3-23 N
Wire feed rate Max. 420 mm/sec
