Sodick MC430L

X-Axis Travel 420 mm
Y-Axis Travel 350 mm
Z-Axis Travel 200 mm
Number of Axes 3
Table Length 600 mm
Table Width 400 mm
Number of T-Slots 5
T-Slot Pitch 80 mm
T-Slot Width 14 mm
Max Table Load 60 kg
Workpiece Diameter 6 mm
Spindle Nose HSK E25
Spindle Nose to Table 115–315 mm
Spindle Speed 6,000–40,000 rpm stepless
Feed Range 0–4,000 mm/min
Rapid Traverse 36 m/min
Tool Magazine 45 positions
Voltage 3x400 V 50 Hz
Machine Weight 5,800 kg
Overall Length 1,625 mm
Overall Width 1,500 mm
Overall Height 2,105 mm
