Stomana KZM 6 RTF

Edge banding machine preliminary milling + corner finishing
thickness of workpieces 8-45mm
minimum length of the workpiece 100 mm
the minimum width of the workpiece 100 mm
edge thickness 0,4-3,0mm
feed speed 9,5m/min
cutting unit - engine power 2 × 0,22kW
milling unit 2 × 0,35kW
milling unit 12000obr / min
corner earning unit - the minimum length of the workpieces 250 mm
aggregate for making corners 1 × 0,35kW
aggregate for making corners 12000obr / min
pre-milling aggregate 1 × 1,1; 1 × 0,75kW
pre-milling aggregate 12000obr / min
polishing unit - engine power 2 × 0,18kW
polisher aggregate 2800obr / min
diameters of guy connections 2x120mm, 2x100mm
compressed air pressure 6,5bar
total power 6,7kW
dimensions length / width / height 4190 / 1050 / 1470mm
weight 1180kg
