Trak, XYZ DPM 1300 Engine Lathe 3600 t/min

Longitudinal travel (X-axis) 1340 mm
Transversal travel (y axis) 430 mm
Vertical travel (z axis) 590 mm
Vertical quill travel 120 mm
Swivel range Vertical milling head +90 / -90 °
PROTO TRAX SMX
Adjustable depth stop
Mechanical handwheels
Chip protector
Machine lamp
Table length 1300 mm
Table width 400 mm
Number of T-channels 5
T-channel width 16 mm
Distance of the T-slots 63 mm
Table load max. 800 kg
Spindle speeds: stepless from 70 t/min up to 3600 t/min
Milling spindle motor 5.5 kW
Taper in spindle 40 ISO
Distance from vertical spindle to table 600 mm
Milling capacity in steel 100 cm3/min
Feeds (X, Y, Z) 25 - 3800 mm/min
Rapid traverse: 3.8 m/min
Drill capacity in steel 35 mm
Threat cutting in steel M 36
Machine's weight about 2400 kg
Length 3790 mm
Width 1800 mm
Height 2500 mm
Voltage 3x 400 Volt 50 Hz
