Uteco DIAMOND HP 108 10 1300mm

Ref : 2722683-4-MT
Condition : Used
Manufacturer : Uteco
Model : DIAMOND HP 108
Number Of Colors : 10
Size : 1300mm
Year(s) : 2015
Quantity : 1
Location : Seller or machines location:
EUROPE (Western and Northern)

GEARLESS CI FLEXO PRESS
Number of colours: 10
Fast sleeve change
4 motor per deck CNC position system
Computer supervision
Web width: 1350 mm
Print width: 1300mm
Minimum print repeat: 400mm
Maximum print repeat: 850mm
Unwind: automatic turret
Maximum reel diameter unwind: 1000mm
Rewind: automatic turret
Maximum reel diameter rewind: 1000mm
Drying: 2 gas burners, 2 zones, thermo oil heat exchangers, 6mt final tunnel
Automatic air recirculation system with LEL control
Video camera: Grafikontrol
Corona treatment: Ferrarini Benelli
Web guides
Viscosity control
Washing system: automatic
Inking system: closed chamber doctor blades and ceramic anilox
+ Anilox
+ Print sleeves
Operator lifting platforms for sleeves change
Automatic LEL control
