Zayer KC 10000 3000 U/min.

Ref : 2717523-3-GO

Condition : Used

Manufacturer : Zayer

Model : KC 10000

Spindle Size : -

Spindle Speed : 3000 U/min.

Year(s) : 1995

Quantity : 1

Location : Seller or machines location:
EUROPE (Western and Northern)

ZAYER KC 10000
Build year 1995

x-travel10000 mm
y-travel1500 mm
z-travel3000 mm

ControlHeidenhain TNC 415B
spindle taper ISO50
speed steps2
speeds infinitely variable35 - 3000 U/min.
feeds6 - 10000 mm/min
rapid traverse longitudinal10000 mm/min
rapid traverse cross15000 mm/min
rapid travel vertical10000 m/min
main drive37 / 100% ED kW
Number of working hours41500 h
weight of the machine ca.39,3 t
dimensions of the machine ca.17,8 x 6,5 m
height of the machine6,2 m
Machine under floor level1905 mm
