Fischer & Krecke EDGEMASTER EMF-28

Edge Strengthening and Trimming Device
Veneer specifications :
Veneer strip length (grain direction) 420 - 2800 mm
Veneer sheet width (cross grain) 400 - 4200 mm
Veneer strip thickness (incl. trimming) 0,3 - 1,5 mm
Veneer strip thickness 0,3 - 2,0 mm

Machine capacity:
Production speed (continuous) 15 - 35 m/min.

Machine specifications:
Cut-off each side 10 - 350 mm
Tape (paper) width 6 mm
Tape (paper) thickness 0,16 mm Type CP-99
Roll (core in- and outside) ∅ 75 mm, ∅ 325 mm
Roll (width) 65 mm
Tape running meter 3200 m
Connection data
Electric energy 1,1 kW
Compressed air 6 bar
Power consumption
Compressed air consumption 5 NL/min
Dimensions / weight
Measurements :
Length 4755 mm
Width 1868 mm
Height 1690 mm
Working height 930 mm (+50/-0 mm)
Net weight, approx. 1350 kg
