Flexotecnica Gonderflex GFLX 2800 10 28.00

FLEXOGRAPHIC-MACHINE
Options :
10 Color Walk In
Maximum printing width 28.00
Maximum paper width 28.00
Printing repeats 9 to 24
Gearing 1/8 circular pitch
Maximum mechanical speed 500ft/min.
Drive 360 register gear box AC vector motor
Servo motor
Substrate Aluminum foil min. 38 micron, film (2 mil) and Papers TWO 3 core shaft electronic sensing web guide splicing table hydraulic roll lift and automatic
Magpower close loop tension control system with electromagnetic brake
Quick change release upgrade 1 Double side corona treatment unit from Pillar including 3.5 KW power
Supply with manual adjustable power control double side web treater stations ozone exhaust blowers with motor starter and 3 stage indicator light green indication one side treatment amber indicating two side treatment and red indicating no treatment 1
Servo motor driven variable in feed air nip roll station with closed loop tension 10
New generation high precision walk in model flexo print stations including Chrome plated impression cylinders
with hardened 1/8 CP gearing 1/8 CP gear drive plate cylinders
Two reversible print station upgrades for first and second print stations
18 enclosed chamber doctor blades system
10 peristaltic ink pumps 24 new
Anilox rollers with quick coupling (no gears on the anilox rollers) 14 ink drip pan 10 low drag,
light weight chill idler rollers (no chiller included)
1 High capacity hot air drying system including
10 High capacity drying cabinets with variable power infrared lamps - hot air supply nozzles
and temperature readout display 5 electrical air heaters 5 high pressure supply air blowers, with drives
