Horizon SB-09

Key Features:
- Fully automatic setup and operation for minimal setup times and high efficiency.
- 9-clamp system for continuous high-speed production.
- Compatible with EVA and PUR hotmelt adhesives (interchangeable glue tanks).
- Two glue application rollers for optimal glue penetration and strong binding.
- Automatic book thickness detection and precise cover scoring (up to 4 scores).
- Flexible cover feeding: SB-09V with roller grip, SB-09VF with rotary grip for flap covers.
- Production speed up to 4,000 books per hour.
- Integration into automated production lines with JDF workflow (pXnet).
- Optional: Quality control via weight checking, image checking, and reject unit.
- Ideal for offset and digital printing, variable book sizes and thicknesses.

Technical Data:
- Number of clamps: 9
- Book block thickness: 1 – 45 mm
- Max. book format: 400 x 280 mm (off-line), 330 x 250 mm (in-line)
- Min. book format: 148 x 105 mm
- Max. cover size: 400 x 660 mm
- Min. cover size: 135 x 220 mm
- Cover weight: 82–302 gsm (normal), 105–348 gsm (coated)
- Speed: up to 4,000 books/hour
- Adhesive: EVA and PUR hotmelt (interchangeable tanks)
- Power supply: 3-phase, 200 V, 50/60 Hz, 23/25 A
- Machine dimensions (system): approx. 4,720 x 1,685 x 1,660 mm
