Kingston Engine Lathe 1200 RPM HD-2690

Swing over bed: 26″
Swing over cross slide: 17.5″
Swing in gap: 35.1″
Gap width in front of face plate: 10-5/8″
Distance between centers: 90″
Bed width: 15-3/4″
Height of center from leg bottom: 44.3″
Spindle bore: 4-1/16″
Spindle bore taper: MT#7 x #5
Spindle nose type: D1-11
Number of spindle speeds: 12
Spindle speed range: 13–1200 RPM
Number of feed changes: 16
Longitudinal feed/rev: 0.0012″–0.039″
Cross feed/rev: 0.0006″–0.0195″
Leadscrew diameter: 1.77″
Leadscrew TPI: 2
Inch threads range: 1–42 TPI (48)
Metric threads range: 0.4–28 mm (44)
Compound travel: 9.5″
Cross slide travel: 15.8″
Tailstock speed: 2-speed
Tailstock quill travel: 9.8″
Tailstock quill diameter: 2.9″
Tailstock taper: MT #5
Main motor: 15 HP
Coolant pump motor: 1/8 HP
Floor space: 47″ W x 140″ L
Weight: 8,000 lbs
Extra large roller steady rest (16″ opening)
Aloris DA Series quick change toolpost with holders
3-jaw chuck (15-3/4″)
5-position carriage stop
Dual foot brake pedals
