Maka ECM 27 R 5-axis

Machine description:
High-performance CNC milling center for 5-axis machining, ideal for aluminum machining and mold making.
– MAKA ECM 27 R with gantry design.
– Equipped with automatic central lubrication and a control cabinet with air conditioning.
– BWO 900C CNC control, 1 MB memory, in the integrated PC.
– BWO RC 910 portable control panel.

– Working areas / cube dimensions: with tool length 130 mm and diameter 60 mm
X-axis: 3,000 mm
Y-axis: 2,250 mm
Z-axis: 800 mm, with 170 mm fixture height
A-axis: 540° (+/- 270°)
B-axis: 200° (+/- 100°)

– Rapid traverse speed:
X/Y-axis: 40 m/min.
Z-axis: 15 m/min.
A/B-axis: 10,000 °/min.

1 x 11 kW milling spindle,
Infinitely variable speed from 2,000 – 17,000 rpm,
With ceramic bearings, liquid cooling.
SK 40 tool holder with tool changer.

1 x chain-driven tool magazine for 12 tools up to 160 mm in diameter, including 2 SK40 tools for an angle drill head (fixed-position coded).
1 x 3,000 x 2,250 mm steel table with threaded holes.
1 x 140 m²/h vacuum pump with 250-liter tank.
1 x vacuum clamping circuit.

Workplace safety:
With protective cabin for the rear of the machine, side access door, and the cabin is open at the top.
Slatted curtain on the operator side and safety bumper on the front of the table.

Repairs/Replacements before delivery:
– Maintenance

Connection values:
Voltage: 400 V (max. +/- 5%), Frequency: 50 Hz
Rated power: 22.5 kW
The use of a residual current device in the machine supply line is not possible.
Operating temperature: 10 – 35° C
Pneumatics: 6 bar, approx. 10 m³/h

Tool holders and machining tools are not included in the scope of delivery.
Used machine, without any warranty or guarantee.

Optional:
Including installation and commissioning with delivery ready for production!

Model/Version:
High-performance CNC milling center for 5-axis machining, ideal for aluminum machining and mold making.
– MAKA ECM 27 R in gantry design.
– Equipped with automatic central lubrication and a control cabinet with air conditioning.
– BWO 900C CNC control system with 1 MB memory in the integrated PC.
– BWO RC 910 portable control panel.

Availability:
The machine is assembled and ready for operation and can be inspected.
