Mazak VC 500A 5X 5 Axis

X-axis travel: 19.7 in
Y-axis travel: 17.7 in
Z-axis travel: 17.7 in
A-axis range: +30° / −110°
C-axis: 360° continuous

Mazatrol Smooth X control
Renishaw RMI-Q probing system
Tool pre-setter
Coolant system
Chip conveyor
Jog handle
Mist-Fit MF-550
Superflow S8 1000

Table diameter: 19.7 in (500 mm)
Max table load: 660 lb (300 kg)

Spindle motor power: 25 HP (18.5 kW)
Rapid traverse X/Y/Z: 1,969 IPM (50 m/min)
Rapid traverse A/C: 75 RPM
ATC capacity: 30 tools
Max tool diameter: 3.94 in (100 mm)
Max tool length: 11.8 in (300 mm)
Max tool weight: 13.2 lb (6 kg)
Positioning accuracy: ±0.0001 in
