Mori Seiki CNC (CELOS SIEMENS 840D CNC COLOR CONTROL) MORI SEIKI MAPPS IV CNC CONTROL - FANUC 31IA 3,000 RPM NT4300 DCG/1500SZ 8 Axis

X1-Axis Travel 29.5"
X2-Axis Travel 7.7"
Z1-Axis Travel 61"
Z2-Axis Travel 60"
Y1-Axis Travel -8.3"
W-Axis Travel Sub Spindle 63"
B-Axis Head Travel +/- 120 Degrees
B-Axis Head Indexing 0.0001
B-Axis Milling Spindle Taper Capto C6
B-Axis Milling Spindle Speed 12,000 RPM
B-Axis Milling Spindle Horsepower 24.7 hp
C-Axis Indexing 1 0.0001
C-Axis Indexing 2 0.0001

Rapid Traverse Rate - X1 1968 ipm
Rapid Traverse Rate - X2 1181 ipm
Rapid Traverse Rate - Z1 1968 ipm
Rapid Traverse Rate - Z2 1181 ipm
Rapid Traverse Rate - Y1 1181 ipm

Control CNC (CELOS SIEMENS 840D CNC COLOR CONTROL)
MORI SEIKI MAPPS IV CNC CONTROL - FANUC 31IA
Probing
Scale Feedback X Axis
Chip Blaster High Pressure Coolant System
Chip Conveyor
Tool Presetter
Assorted Capto Holders
Hobbing Software
Chiller
Swing Over Bed 28.7"
Turning Diameter 25.9"
Turning Length 59"
Distance Between Spindles 73"
Chuck Size 1 12"
Spindle Nose 1 A2-8
Spindle Bore Diameter 1 4.1"
Bar Capacity 1 3.15"
Spindle Speeds 1 3,000 RPM
Spindle Horsepower 1 30 hp
Chuck Size 2 12"
Spindle Nose 2 A2-8
Spindle Bore Diameter 2 4.1"
Bar Capacity 2 3.15"
Spindle Speeds 2 3,000 RPM
Spindle Horsepower 2 30 hp
Turret Tool Positions 1 10 Station
Turret Rotary Tool Speeds 1 6,000 RPM
Turret Rotary Tool Horsepower 1 7.5 hp
Machine Weight 59,000 lb
Tool Diameter 2.7" / 5.5"
Tool Length 15.7"
Tool Weight 22 lb
