POSMILL H 500 U 3 Axis

X-axis travel 650 mm
Y-axis travel 850 mm
Z-axis travel 500 mm
Rotary table 360° endless
Heidenhain iTNC 530 control
Spindle speed 18,000 rpm
Spindle taper HSK-A63
60-position tool changer
Through-spindle coolant 20 bar with belt filter
Air through spindle
Kessler rotary table diameter 500 mm
Infrared workpiece measurement 3D probe
Tool measurement with BLUM laser
Rotating viewing window
POS DCM collision module
Mobile electronic handwheel
Oil mist extraction
Heidenhain linear measuring system X/Y/Z
Protective air for all linear measuring systems
Active switch cabinet cooler air-air
Active cooling for 4th and 5th axis, controlled
Network connection
USB connection
Spindle cooler, controlled
Heidenhain rotary measuring system
POS contour protection
Hinged belt chip conveyor external
Coolant pump at spindle head via M-functions
Chip flushing device pump
Chip flushing device
Operating status light
Spindle air
Oil/coolant separator electromechanical
Automatic coolant level monitoring
3-way media connection in table center
Hydraulic unit with M-function control
Power requirement 60 kVA
Machine dimensions 4800 x 4600 x 3000 mm
IKZ unit dimensions 2200 x 1300 x 1400 mm
Machine weight 13,000 kg
