SCM MINIMAX ST-01

Combined Saw-Spindle Moulder
Condition: Used
Availability: In stock

Technical specifications:
Circular saw
Max. blade diameter: 250 mm
Blade tilt: 90° to 45°
Max. cutting height at 90°: 75 to 80 mm
Max. cutting height at 45°: 60 to 64 mm
Cutting width at parallel fence: 700 mm
Anodized aluminum carriage (flush with blade)
Carriage stroke: 3,200 mm

Spindle moulder
Spindle diameter: 30 mm
Useful spindle length: 75 mm
Rotation speeds: 5,000 / 7,500 rpm
Max. tool diameter (profiling): 160 mm
Max. tool diameter (under-table): 145 mm
Max. tool diameter (tenoning): 200 mm
Spindle moulder fence with micrometric adjustment
Motorization
Three-phase motor: 1.8 kW (50 Hz) or 2.2 kW (60 Hz)
Spindle moulder: 5 kW
Saw: 5 kW
Dust extraction outlet diameter: 120 mm
Construction
Cast iron work table
Anodized aluminum sliding carriage
Robust monoblock frame
Safety guards compliant with CE standards
Compact footprint, ideal for carpentry, cabinetmaking, and interior fitting workshops
