Sintesy 1616 S Automatic laminating machine

Oppliger brand automatic laminating machine
Size 1650x1650 mm
- TANGO 1616 S³ Laminating Machine
- Sheet feeder with automatic suction head for covering material, S³ version
- Descent bridge version S³
- Suction belt feeder for backing material, S³ version
- High-tech low consumption glue unit version S³
- Top-of-the-range line coupler group, S³ version
- Uphill treadmill Slow S³ version
- Bundle forming unit, bundle turning unit, stacker version S³
- Place the pallet
- Touch Screen Siemens version S³
- Non-Stop exit 600 mm

Technical Data:
Length of the machine offered: 16.9 meters
• Glue Group Speed: 60 ÷ 150 m/min
• Feeder Speed: 1,000 ÷ 9,000 sheets/h*
• Support material: F – E – B – C s.f.& d.f. EE – EB – BC d.w.,laminil
• Minimum thickness 0.7 mm *
• Maximum thickness 10.2 mm*
• Covering material: 120 ÷ 500 gr/m2 *
• Minimum format: 480 x 480 mm
• Maximum format: 1,650 x 1,650 mm
• Maximum height of the incoming stack 1,700 mm (max. 2,000 kg)

Optional extras included:
Optional Edge-to-Edge
Optional Teso-Teso - Minimum support weight 400g/m2 and minimum thickness 0.8mm
Optional Video Surveillance System with LED Monitor and 4 Cameras
Teleservice router
Optional 2STS System (Two Steps Tool System)
Machine with installation in the hole
Pallet change on exit
