Southwestern Industries ProtoTRAK SLX CNC 1800 RPM TRL 2470SX 2 Axis

Control: ProtoTRAK SLX CNC
Cross slide travel: 12.5"
Rapid traverse: 250 IPM
ProtoTRAK SLX CNC control
Dynamic spindle motor brake
Direct drive headstock
Dual sliding chip/coolant doors
Removable sliding door
Meehanite cast monolithic base
Heavy ribbed base construction
Hardened and ground bedways
Turcite-coated sliding surfaces
Dovetail cross slide with V-ways
Adjustable saddle gibs
Bar capacity (spindle bore): 4.09"
Swing over bed: 24"
Swing over saddle wings: 24"
Swing over cross slide: 14.5"
Distance between centers: 70"
Center height: 12"
Spindle speed: 40–670 / 100–1800 RPM
Spindle motor: 15 HP
Spindle nose: D1-8
Spindle taper: MT #8
Front spindle bearing diameter: 5.51"
2 spindle speed ranges
2 spindle bearings
Tailstock quill travel: 8.5"
Tailstock quill diameter: 3.5"
Tailstock quill taper: MT #5
Dorian Smart DEX 25N power turret
12" BTC 3-jaw chuck
Tool post
Collet closure
Coolant capacity: 15 gal
Coolant pump motor: 1/8 HP
Bed width: 14.57"
Bed height: 15"
Machine dimensions: 129" × 60" × 77"
Machine weight: 6,500 lbs
