Topper TCS 2000II

Z-Axis Travel: 15.75"
X-Axis Travel: 5.9"
Rapid Traverse X/Z: 1181 IPM
Control: Fanuc 0i-TF Plus CNC
10.4" LCD Display
Bar Feeder Interface
Manual Tool Presetter
Oil Skimmer
Bar Capacity: 2.01"
Swing Over Bed: 20.47"
Swing Over Carriage: 12.6"
Standard Turning Diameter: 11.8"
Distance Between Centers: 19.7"
Spindle Speed: 45–4500 RPM
Spindle Motor: 20 HP
Spindle Nose: A2-6
Spindle Bore: 2.4"
Spindle Bearing Diameter: 3.9"
Spindle Taper: MT5
Hydraulic 8" 3-Jaw Chuck
12-Station Servo Turret
Tool Mounting: Block Type or VDI
OD Tool Size: 1"
ID Tool Size: 1.25"
Tailstock
Tailstock Quill Diameter: 2.95"
Tailstock Quill Stroke: 3.94"
Tailstock Taper: MT4
Manual Tailstock Body Travel: 10.8"
Cutting Feed Rate: 0.0001–19.7 IPR
Positioning Accuracy: ±0.0002"
Repeatability: 0.0001"
Coolant Tank Capacity: 30 gal
Coolant Pump Motor: 0.5 HP
Chain-Type Chip Conveyor
Chip Conveyor Trolley
Machine Dimensions: 128" × 87" × 72"
Machine Weight: 7,700 lbs
