Toshiba EC200SXIV70-048 200 T

This high‑performance injection molding machine offers a 200‑ton clamping force and
6.3 oz injection capacity, ideal for precision molding applications.
Built in 2022, it features Toshiba’s all‑electric drive system for ultra‑quiet operation,
minimal maintenance and excellent energy efficiency.
The machine’s modern controls and compact footprint make it a strong choice for
high‑quality production runs across a wide range of plastics.

Type All Electric
Clamping Force Tonnage 200 T
Shot Volume (PS) 6.3 oz
Screw Diameter 2.16"
Tie Bar Distance H 22"
Tie Bar Distance V 22"
Platen Dimension H 31"
Platen Dimension V 29.1"
Maximum Daylight 41.3"
Mold Height Min 7.9"
Mold Height Max 23.3"
Hours 5,007,540 hr.

EQUIPPED WITH:
INJECTVISOR V70 CONTROL
WIRED FOR CORE PULL
ONLY APPROX 5007 HOURS (542,538 SHOTS)
